Elgin 730
Jewels: 17
Frequency: 18000 vph
Type: Manual Wind
Period used: 1940-1948
Size: 12.75 x 17 mm
Hands: 0.90 x 0.50 mm
The Elgin 730 watch movement was produced from 1940 to 1948, with a total of 635,000 units manufactured. It belongs to the Model 4 category. The movement features manual winding and a sweep second function.
The Elgin 730 features the following functions:
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.27 x 0.076 x 7.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| PALLET FORK/ARBOR | 6467/ELG | Buy part |
