Elgin 716
Ligne: 6.75 x 8'''
Jewels: 17
Power Reserve: 48 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: 1977-1979
Size: 15.3 x 18.2 mm
Height: 3.6 mm
Hands: 1.10 x 0.60 mm
Base: Fontainemelon 69N
The Elgin 716 is a manual wind watch movement that was introduced as the USA version of the 2137. It features an Adjustable Stud Holder and Shock Protection. This movement was utilized during the period of 1977-1979.
The Elgin 716 features the following functions:
- Adjustable Stud Holder
- Manual Winding
- Shock Protection
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.080 x 240 x 7.0 mm | GR4445 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
