Elgin 712
Ligne: 4.5 x 10.25'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1935
Size: 10 x 23.1 mm
Height: 3.6 mm
Hands: 1.10 x 0.60 mm
The Elgin 712 is a mechanical watch movement that was originally introduced around 1935. It is a manual wind movement. Beyond these basic specifications, information regarding the specific differences between the ETA 651, 652, 654, 655, and 658 movements is currently not available.
The Elgin 712 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.070 x 210 x 6.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
