Elgin 366
Ligne: 5.75 x 8.5'''
Jewels: 17
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Size: 12.8 x 19.55 mm
Height: 3.4 mm
Hands: 1.00 x 0.60 mm
The Elgin 366 watch movement, also known as the Recta 518 or MV518, is a manual wind calibre with dimensions of 3.2mm and 3.6mm in height. Some references also mention a height of 3.0mm without providing information on the stem, staff, and mainspring. It was commonly used around the period of 1940.
The Elgin 366 features the following functions:
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.10 x 0.090 x 220 x 7.0 mm | GR2591 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
