Dugena 2113
Jewels: 7
Frequency: 18000 vph
Type: Manual Wind
Period used: 1915-1917
Diameter: 27.94 mm
The Dugena 2113 watch movement is an open face calibre, model 5, that was produced from 1915 to 1917 with 129,000 units made. It features a bimetallic screw balance and Breguet hairspring, utilizing a negative stem mechanism. Similar to the 0 size model 3, it has a smaller base plate. The specific differences between models 3, 5, and 7 are currently unknown. The Dugena 2113 movement is equipped with stem wind and set capabilities, as well as a sub second function.
The Dugena 2113 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
