Cyma Tavannes 955
(Cyma, Tavannes)
Ligne: 8.75 x 12'''
Jewels: 15
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1933-1958
Size: 20 x 26.55 mm
Height: 4.0 mm
Hands: 1.25 x 0.65 / 0.18 mm
The Cyma Tavannes 955 is a manual wind, sub-second mechanical movement that was used from 1933 to 1958. It is the first caliber developed by PUW, and there are four distinct generations of this movement with non-interchangeable parts.
The Cyma Tavannes 955 features the following functions:
- Manual Winding
- Mechanical Movement
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 2919 | Ordinary/None | Buy staff |
| 3102 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.120 x 290 x 10.0 mm | Manual | Buy mainspring | |
| 1.20 x 0.125 x 300 x 9.5 mm | GR2980 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
