Cyma Tavannes 910
(Cyma, Tavannes)
Jewels: 17
Lift Angle: 70°
Power Reserve: 42 hrs
Frequency: 19800 vph
Type: Manual Wind
Period used: ~1963
Size: 12.5 x 15.5 mm
Height: 3.2 mm
Hands: 0.90 x 0.50 mm
The Cyma Tavannes 910 watch movement is a manual wind movement that features a straight lever escapement. It is equipped with an adjustable stud holder to aid in regulating the timekeeping of the watch. The movement also incorporates the Incabloc shock protection system to help protect against shock and external impacts. The Cyma Tavannes 910 movement was commonly used in watches manufactured around 1963.
The Cyma Tavannes 910 features the following functions:
- Adjustable Stud Holder
- Incabloc Shock Protection
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 4310 | Ordinary/None | Buy staff |
| 5105 | Ordinary/None | Buy staff |
| 4310 | Incabloc | Buy staff |
| 5105 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.070 x 180 x 5.5 mm | GR3574 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More | |||
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
