Cyma Tavannes 13
(Cyma, Tavannes)
Ligne: 11.5'''
Jewels: 17
Frequency: 19800 vph
Type: Manual Wind
Period used: ~1960
Diameter: 26 mm
Base: Certina 180
The Cyma Tavannes 13 watch movement is a manual wind movement that features a subsecond and sweep seconds function. Developed by Record, the movement was later adopted by Longines upon acquiring Record. It is uncertain if additional variants of the movement were available as Wittnauer calibers. While manual-wind versions and automatic versions without date are known to exist, they have primarily been observed in Wittnauer watches rather than those produced by Record or Longines. The Cyma Tavannes 13 movement was commonly employed around the 1960s.
The Cyma Tavannes 13 features the following functions:
- Manual Winding
- Sub Second
- Sweep Seconds
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.110 x 300 x 9.0 mm | GR4149 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
