Cattin C66
Ligne: 13'''
Jewels: 15/17
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 29.4 mm
Height: 3.85 mm
Hands: 1.50 x 0.90 / 0.21 mm
The Cattin C66 is a manual wind watch movement with a sub-second function. It is part of the Wehrmachtswerk series, specifically the 6310N, 6311N, 6312N, and 6318N models. The differences between these models are unknown, but they likely designate varying bridge shapes. The movement features an Adjustable Stud Holder and Shock Protection.
The Cattin C66 features the following functions:
- Adjustable Stud Holder
- Manual Winding
- Shock Protection
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.75 x 0.135 x 360 x 11.5 mm | GR5171 | Manual | Buy mainspring |
| 1.70 x 0.130 x 360 x 11.5 mm | Manual | Buy mainspring | |
| 1.70 x 0.130 x 340 x 11.0 mm | GR4958 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
