Bettlach 8103
(EB)
Ligne: 11.5'''
Jewels: 17
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Automatic
Diameter: 26 mm
Height: 5.2 mm
Hands: 1.50 x 0.90 x 0.21 mm
The Bettlach 8103 watch movement is a detached manual wind movement whose differences are not known compared to the 1624 movement. It is equipped with 1. automatic and 2. sweep second functions.
The Bettlach 8103 features the following functions:
- Automatic Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.100 x 340 x 10.0 mm | GR2922X | Auto | Buy mainspring |
| 1.20 x 0.100 x 315 x 9.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
