Bettlach 1404
(EB)
Ligne: 5.75 x 6.75'''
Jewels: 17
Lift Angle: 50°
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Size: 13 x 15.2 mm
Height: 3.4 mm
Hands: 1.10 x 0.61 mm
Base: MSR B1
The Bettlach 1404 is a mechanical watch movement with manual wind functionality. It was produced around 1955. It shares certain similarities and differences with the Revue B1 and MSR B1 movements, but the specific details of these differences are not currently known.
The Bettlach 1404 features the following functions:
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.070 x 220 x 6.0 mm | GR4816 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| DATE JUMPER | A/4262 | 8012/ROL 1555 | Buy part |
| PALLET ARBOR | 72S/10P | 714/ETA 2890 | Buy part |
| ROLLER 155X75X33 | 82S/143R | 730/36 | Buy part |
| STAFF, INCA | 100/2412 | Buy part | |
| STEM | 200/1555F | Buy part |
