Benrus DS1D
Ligne: 5.5 x 7'''
Jewels: 17
Power Reserve: 47 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Size: 12.15 x 15.9 mm
Height: 3.5 mm
Hands: 1.00 x 0.55 mm
Base: Fleurier 430
The Benrus DS1D watch movement is a manual-winding mechanical movement, commonly used around the period of 1950. There are some differences between the Fleurier 430 and 434 movements, but these differences are not known.
The Benrus DS1D features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.065 x 220 x 6.0 mm | GR3568 | Manual | Buy mainspring |
| 1.40 x 0.070 x 240 x 5.5 mm | GR35771 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| ARBOR, PALLET 31X90X8 | 72S/15P | 72S/15P | Buy part |
| BALANCE COMPLETE, INCA W/SCREW | 721/1034 | 721/FEF 430 | Buy part |
| FOURTH WHEEL, SS *GENERIC* | 227/911 | J-5014/ROL 3035 | Buy part |
| MAINSPRING 1.40-.07-240 5,5 | MS-514E | GR 3577-1 | Buy part |
| ROLLER 155X75X33 | 82S/143R | 730/36 | Buy part |
| ROLLER 155X75X33 | 82S/9R | Buy part | |
| STAFF, HSP 45 ROL 33 | 100/36 | 56/BUL 5AC,5BA | Buy part |
| STEM, ALARM | 200/1326F | Buy part |
