Baumgartner 421
Ligne: 5.75 x 8.5'''
Jewels: 17
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Size: 12.85 x 19.5 mm
Height: 3.8 mm
Hands: 1.20 x 0.60 mm
The Baumgartner 421 watch movement is part of a series of movements, including the 2340-2343, 2345-2353, 2353a, 2354a, 2355, and 2356, which have differences that are not known. The Baumgartner 421 is a manual wind movement that was used around the period of 1950.
The Baumgartner 421 features the following functions:
- Manual Winding
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.085 x 265 x 8.0 mm | Manual | Buy mainspring | |
| 1.60 x 0.085 x 260 x 7.5 mm | GR4455 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
