A. Schild 912
(AS, A Schild)
Ligne: 18.5'''
Jewels: 15
Power Reserve: 35 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1925
Diameter: 42 mm
Height: 5.0 mm
Hands: 1.85 x 1.15 / 0.21 mm
Base: Junghans J17
The A. Schild 912 watch movement, introduced around 1925, features a hunter calibre design. It is equipped with a monometallic screw balance that incorporates a press-fit staff, ensuring precise timekeeping. The movement is further enhanced by the inclusion of a Breguet hairspring, which contributes to its accuracy. The A. Schild 912 offers stem wind and set functionality, along with a sub-second indicator.
The A. Schild 912 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 2.00 x 0.200 x 460 x 16.0 mm | GR5902 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
