A. Schild 701
(AS, A Schild)
Ligne: 5.75 x 6.75'''
Jewels: 17
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1949
Size: 13 x 15.3 mm
Height: 3.4 mm
Hands: 1.00 x 0.42 mm
The A. Schild 701 watch movement is a manual wind movement that was used in watches around the period of 1949.
The A. Schild 701 features the following functions:
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 904 | Ordinary/None | Buy staff |
| 1628 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.065 x 220 x 6.0 mm | GR3179T | T | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
