A. Schild 2186
(AS, A Schild)
Ligne: 11.5'''
Jewels: 25
Lift Angle: 52°
Power Reserve: 47 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1969-1982
Diameter: 26 mm
Height: 5.3 mm
Hands: 1.50 x 0.90 x 0.25 mm
The A. Schild 2186 watch movement was produced from 1969 to 1982, with over 25 million units manufactured during that time. It is equipped with a precision regulator, featuring either an excenter or Triovis system. This movement offers automatic winding functionality, along with a sweep seconds hand. Additionally, it includes a date function, which can be adjusted by changing the time between 20 and 24 hours. Some versions of the A. Schild 2186 also offered an optional hack feature.
The A. Schild 2186 features the following functions:
- Automatic Winding
- Date: set by changing 20-24h
- Optional hack feature
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.125 x 400 x 11.0 mm | GR4006X | Auto | Buy mainspring |
| 1.45 x 0.120 x 368 x 10.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
