A. Schild 2162
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17/28/44
Lift Angle: 52°
Power Reserve: 43 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1965-1973
Diameter: 26.4 mm
Height: 5.35 mm
Hands: 1.50 x 0.90 x 0.21 mm
The A. Schild 2162 watch movement, used from 1965 to 1973, features a rotor bearing with 7 ruby balls and a total of 44 jewels. It is a detached manual wind movement with variations in the base plate and date disc during its production period. The movement is available with different rotor shapes, namely: 1) like MST 437, 2) without slot, 3) with slot, and 4) with slot, nickel plated. In addition, the movement offers automatic winding, sweep second function, and a date display that can be set by changing from 21:15 to 24h. The A. Schild 2162 movement also incorporates Incabloc Shock Protection.
The A. Schild 2162 features the following functions:
- Automatic Winding
- Date: set by changing 21:15-24h
- Incabloc Shock Protection
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.100 x 300 x 9.5 mm | GR3254X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
