A. Schild 1985
(AS, A Schild)
Ligne: 11.5'''
Jewels: 21
Lift Angle: 49°
Power Reserve: 32 hrs
Frequency: 18000 vph
Type: Automatic
Period used: ~1965
Diameter: 25.6 mm
Height: 5.0 mm
Hands: 1.30 x 0.90 mm
The A. Schild 1985 watch movement is a pin-lever escapement with automatic winding and a sub-second function. It was first introduced around 1965.
The A. Schild 1985 features the following functions:
- Automatic Winding
- Pin lever
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.25 x 0.085 x 7.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
