A. Schild 1831
(AS, A Schild)
Ligne: 11.5'''
Jewels: 22
Power Reserve: 42 hrs
Frequency: 28800 vph
Type: Automatic
Period used: ~1990
Diameter: 26.2 mm
Height: 3.6 mm
Hands: 1.50 x 0.90 x 0.25 mm
Base: ETA 2892
The A. Schild 1831 watch movement features hand heights similar to the 37524 movement, with a reduced magnetic field. Its rotor weight is made of 21K gold. For further technical details, reference can be made to the ETA 2892 movement. It functions as an automatic movement with a sweep second hand, quickset date, and hack feature. This movement was commonly used during the period of approximately 1990.
The A. Schild 1831 features the following functions:
- Automatic Winding
- Date: quickset
- Hack feature
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.05 x 0.115 x 475 x 10.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
