A. Schild 1714
(AS, A Schild)
Ligne: 6.75 x 11'''
Jewels: 15
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1936
Size: 15.2 x 24.6 mm
Hands: 1.50 x 0.80 mm
The A. Schild 1714 is a mechanical watch movement with a manual winding function. It was introduced around 1936 and offers the option of a digital display, specifically showing the minutes and jumping hour. While there is limited information available, no specific differences between the A. Schild 1714 and the A. Schild 804 watch movements are known.
The A. Schild 1714 features the following functions:
- Manual Winding
- Option: Digital display - minute, jumping hour
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.100 x 300 x 9.0 mm | GR4122 | Manual | Buy mainspring |
| 1.50 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
