A. Schild 1691
(AS, A Schild)
Ligne: 10.5'''
Jewels: 15/17
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1935
Diameter: 23.3 mm
Hands: 1.40 x 0.80 mm
The A. Schild 1691 is a mechanical watch movement with a bimetallic screw balance. It shares similarities with other Felsa movements such as the 71, 73, 75-80, 144, 166, 167, 203, 205, 216, 219, 240, 244, 255, 268, 284, 286, 287, but specific differences are not known. The A. Schild 1691 movement was commonly used in watches from around 1935 and features manual wind and sub second functionalities.
The A. Schild 1691 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
