A. Schild 1635
(AS, A Schild)
Ligne: 13.25'''
Jewels: 25
Lift Angle: 49°
Power Reserve: 46 hrs
Frequency: 28800 vph
Type: Automatic
Period used: 2002-
Diameter: 30.4 mm
Height: 7.9 mm
Hands: 2.00 x 1.20 x 0.25 / 0.18 x 0.18 x 0.18 mm
Base: Valjoux 7750
The A. Schild 1635 is an automatic chronograph watch movement with a 60-second, 30-minute, and 12-hour cam switched counters. It features a sub second function and a date function which can be set using the pusher at 10 o'clock. The movement also has a hack feature, allowing for precise time setting. The A. Schild 1635 is a reliable and widely used movement, employed in watches from the year 2002 onwards.
The A. Schild 1635 features the following functions:
- Automatic chronograph, 60s, 30min, 12h, cam switched
- Date: set by pusher at 10h
- Hack feature
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.117 x 620 x 12.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| ADDITIONAL DRIVE WHEEL | A/9650 | 1503/ETA 7753 | Buy part |
| ADDITIONAL MINUTE COUNTING WHL | A/9686 | 35.020.00.7753 | Buy part |
| CALENDAR PLATFORM | A/9659 | 2551/ETA 7753 | Buy part |
| CALENDAR SETTING WHEEL | A/9677 | 2563/ETA 7753 | Buy part |
| COMBINED MAINTAINING PLATE | A/9662 | 2537/ETA 7753 | Buy part |
| CORRECTOR YOKE SPRING | A/9679 | 2769/ETA 7753 | Buy part |
| DATE CORRECTOR | A/9681 | 2566/ETA 7753 | Buy part |
| DATE CORRECTOR YOKE | A/9678 | 2765/ETA 7753 | Buy part |
| DATE DIAL, BLACK ON WHITE @3 | A/9673 | 2557/ETA 7753 | Buy part |
| DATE DIAL, WHITE ON BLACK @3 | A/9674 | 2557/ETA 7753 | Buy part |
| DATE DRIVE WHEEL | A/9661 | 2556/ETA 7753 | Buy part |
| DATE JUMPER | A/9682 | 2576/ETA 7753 | Buy part |
| DATE JUMPER SPRING | A/9680 | 2575/ETA 7753 | Buy part |
| HOUR COUNTER LOCK | A/9873 | 8690/VAL 7753 | Buy part |
| HOUR RECORDING WHEEL | A/9710 | 8600/ETA 7753 | Buy part |
| HOUR WHEEL, DOUBLE | A/9675 | 2558/ETA 7753 | Buy part |
| MINUTE COUNTER INTER WHEEL | A/9683 | 8042/ETA 7753 | Buy part |
| MINUTE COUNTING WHEEL | A/9676 | 8020/ETA 7753 | Buy part |
| OSCILLATING PINION 60S | A/8039 | 08086.7750.476601 | Buy part |
