A. Schild 1576
(AS, A Schild)
Ligne: 17'''
Jewels: 16
Power Reserve: 34 hrs
Frequency: 18000 vph
Type: Manual Wind
Diameter: 38.7 mm
Height: 5.05 mm
Hands: 1.75 x 1.10 / 0.22 mm
The A. Schild 1576 is an open face calibre watch movement, featuring a Breguet hairspring. While the jewel count differences between the 735 and 775 are not known, it is likely that the only variation lies in the dial fixing with thread-cutting nuts. The movement offers stem winding and setting functionality, as well as a sub-second display.
The A. Schild 1576 features the following functions:
- Stem wind and set
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.80 x 0.180 x 450 x 15.0 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
