A. Schild 1571
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17
Power Reserve: 44 hrs
Frequency: 18000 vph
Type: Automatic
Period used: ~1942
Diameter: 26.3 mm
Height: 5.85 mm
Hands: 1.50 x 0.90 x 0.20 mm
The A. Schild 1571 watch movement, developed in 1942, is the first caliber to feature bidirectional rotor winding. It belongs to the pilot series for the family 690 through 699, sharing a similar base-plate. Examples of the A. Schild 1571 caliber with a calendar corresponding to the 693 are also known. This movement is automatic, has sub seconds, and its period of use is approximately 1942.
The A. Schild 1571 features the following functions:
- Automatic Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 987 | Ordinary/None | Buy staff |
| 2706 | Incabloc | Buy staff |
| 2897 | Incabloc | Buy staff |
| 3182 | Supershock | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.110 x 320 x 10.0 mm | GR3983X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
