A. Schild 1523
(AS, A Schild)
Ligne: 12.5'''
Jewels: 21
Lift Angle: 46°
Power Reserve: 41 hrs
Frequency: 21600 vph
Type: Automatic
Period used: 1970-
Diameter: 28.4 mm
Height: 4.5 mm
Hands: 1.52 x 1.00 x 0.17 mm
The A. Schild 1523 watch movement, manufactured from 1970 onwards, incorporates jewel bearings for the barrel. This movement is equipped with various functionalities including an automatic mechanism, a sweep second hand, and a quickset date feature.
The A. Schild 1523 features the following functions:
- Automatic Winding
- Date: quickset
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| PALLET FORK AND ARBOR | 035-39 | 710/1344 | Buy part |
| ROLLER | 044-02 | 730/64 | Buy part |
| STEM, GENUINE | 065-99 | 401/766 | Buy part |
