A. Schild 1479
(AS, A Schild)
Ligne: 11.75'''
Jewels: 17/19
Lift Angle: 52°
Power Reserve: 41 hrs
Frequency: 18000 vph
Type: Automatic
Period used: 1951-1959
Diameter: 26.8 mm
Height: 5.5 mm
Hands: 1.15 x 0.78 x 0.16 mm
The A. Schild 1479 watch movement is an automatic (bumper) movement with a sub second function. It features a day function that can be set by changing the 21-24 hour marker and a date function that can be set using a pusher at the 4 o'clock position. The movement also includes Incabloc Shock Protection and a calendar function. This movement was used during the period of 1951-1959.
The A. Schild 1479 features the following functions:
- Automatic (bumper)
- Calendar
- Date: set by pusher at 4h
- Day: set by changing 21-24h
- Incabloc Shock Protection
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.100 x 300 x 9.5 mm | GR3254X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
