A. Schild 1476
(AS, A Schild)
Ligne: 11.5'''
Jewels: 25
Power Reserve: 33 hrs
Frequency: 18000 vph
Type: Automatic
Period used: ~1955
Diameter: 26 mm
Height: 6.6 mm
Hands: 1.30 x 0.80 x 0.22 mm
The A. Schild 1476 watch movement was developed in 1955 and features a detached manual wind mechanism with wheels made of beryllium bronze. Despite its short production run of approximately one year, two variants of the manual wind gear and two balances were produced in parallel, suggesting an experimental nature. The movement encompasses various functions including automatic winding, sweep second hand, date display, and a calendar. Its period of use is estimated to be around 1955.
The A. Schild 1476 features the following functions:
- Automatic Winding
- Calendar
- Date
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 4138 | Ordinary/None | Buy staff |
| 4138 | Duroswing | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.090 x 9.5 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
