A. Schild 1401
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17
Lift Angle: 52°
Power Reserve: 46 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1970
Diameter: 26 mm
Height: 3.2 mm
Hands: 1.50 x 0.90 x 0.21 mm
Base: A. Schild 1714
The A. Schild 1401 watch movement is a manual wind movement with a sweep second function, sweep seconds, and a calendar. The date can be set by changing the 20-24h. It is characterized by a big balance and low profile design. The movement was commonly used around 1970.
The A. Schild 1401 features the following functions:
- Calendar
- Date: set by changing 20-24h
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.00 x 0.120 x 330 x 10.5 mm | Manual | Buy mainspring | |
| 1.00 x 0.115 x 340 x 10.0 mm | GR24641 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
