A. Schild 1378N
(AS, A Schild)
Ligne: 18'''
Jewels: 15
Power Reserve: 36 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1930
Diameter: 40.6 mm
Height: 4.55 mm
Hands: 1.94 x 1.09 / 0.26 mm
The A. Schild 1378N is an open face calibre watch movement with similarities to the 400, 785, and 900, although specific differences are not known. This movement features stem winding and setting, as well as a sub-second function. It was primarily used during the approximate time period of 1930.
The A. Schild 1378N features the following functions:
- Stem wind and set
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.50 x 0.200 x 460 x 16.0 mm | Manual | Buy mainspring | |
| 1.50 x 0.200 x 460 x 15.5 mm | GR4352 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
