A. Schild 1364
(AS, A Schild)
Ligne: 14'''
Jewels: 17
Lift Angle: 56°
Frequency: 18000 vph
Type: Automatic
Period used: ~1960
Diameter: 31.6 mm
Height: 7.5 mm
Hands: 2.10 x 1.30 x 0.90 x 0.20 mm
Base: Jaeger Lecoultre 489
The A. Schild 1364 movement is an automatic/manual-wind alarm watch. The watch itself is automatic, while the alarm function requires manual winding. It features a sweep second hand and offers a date function that is set by changing the time between 23 and 2 hours. This movement was commonly used in watches around the period of 1960.
The A. Schild 1364 features the following functions:
- Alarm: manual wind
- Automatic Winding
- Automatic/manual-wind alarm
- Date: set by changing 23-2h
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.15 x 0.110 x 375 x 11.0 mm | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
