Return To ShopThe A. Schild 1361N watch movement is the equivalent of the Record 1955 and Longines 501 movements, with the exception of the rotor design. It is a Record design that was later adopted by Longines after acquiring Record. It is unclear if there were other variants available as Wittnauer calibres. Manual-wind versions and automatic versions without a date have been observed from Wittnauer, but not yet from Record or Longines. The specific differences between the C11KAS and C11KAS1 are not known. This automatic movement features a sweep second hand and a date function that can be set by changing the time to 19:30-24h. It was primarily used around the year 1968.
The A. Schild 1361N features the following functions:
Ronda Reference # | Shock System | Buy |
---|
Dimensions | GR Reference # | End Type | Buy |
---|---|---|---|
1.10 x 0.115 x 320 x 10.0 mm | GR2644X | Auto | Buy mainspring |
Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
---|
Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
---|
Part Description | Reference # | Alternate | Buy |
---|---|---|---|
BARREL COMPLETE | 180/1-LON 501 | Buy part | |
CALENDAR CORRECTOR SPRING | 2572/WIT C11KAS | 2572/WIT C11KAS | Buy part |
DRIVE GEAR | 1482/WIT 11KAS | Buy part | |
MAINSPRING 1.10-.115-325 | MSN-81 | GR 2644-X | Buy part |
OSCILLATING WEIGHT AXLE | 1496/WIT 11KA | 1496/WIT 11KA | Buy part |
STAFF, INCA B89 H60 | 100/2120 | 723/AS 1649 | Buy part |
