A. Schild 1360
(AS, A Schild)
Ligne: 10.5'''
Jewels: 15
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1935-
Diameter: 23.7 mm
Height: 3.75 mm
Hands: 1.40 x 0.65 / 0.15 mm
The A. Schild 1360 watch movement, produced from 1935 onwards, features a bimetallic screw balance and a Breguet hairspring. This manual wind movement incorporates a sub second function.
The A. Schild 1360 features the following functions:
- Manual Winding
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.100 x 250 x 8.5 mm | Manual | Buy mainspring | |
| 1.40 x 0.100 x 320 x 9.0 mm | GR3665 | Manual | Buy mainspring |
| 1.40 x 0.090 x 300 x 8.5 mm | GR3629 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
