A. Schild 1320
(AS, A Schild)
Ligne: 12'''
Jewels: 17
Lift Angle: 55°
Power Reserve: 47 hrs
Frequency: 21600 vph
Type: Automatic
Period used: ~1984
Diameter: 27.4 mm
Height: 5.35 mm
Hands: 1.50 x 0.90 x 0.20 mm
The A. Schild 1320 watch movement features a ball-bearing rotor and a sophisticated excenter self-winding mechanism with just one gear stage. It has no hairspring stud, with the hairspring clamped directly in the terminal. This movement shares many parts and casing dimensions with equivalent models of the 61XX family. Its functions include automatic winding, sweep seconds, a day display with quickset in two languages, and a quickset date display. Additionally, it indicates the hours, minutes, and central seconds. The A. Schild 1320 movement was commonly used around 1984.
The A. Schild 1320 features the following functions:
- Automatic Winding
- Central seconds
- Day and Date Display
- Hours
- Minutes
- No Manual Wind
- Quickset date
- Quickset day (2 languages)
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
