A. Schild 12.5
(AS, A Schild)
Ligne: 6.75'''
Jewels: 17
Lift Angle: 52°
Power Reserve: 40 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: ~1965
Diameter: 15.55 mm
Height: 3.4 mm
Hands: 1.20 x 0.60 mm
Base: ETA 2412
The A. Schild 12.5 watch movement features Girocap combined settings for the escapement wheel and an indirectly driven minute allowing for a large balance. Differences between the 23, 231, and 232 models are unspecified. The movement includes functions such as manual winding, an adjustable stud holder, and KIF shock protection. It was used during the approximate period of 1965.
The A. Schild 12.5 features the following functions:
- Adjustable Stud Holder
- KIF Shock Protection
- Manual Winding
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.070 x 220 x 6.0 mm | GR3576 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
