A. Schild 1266
(AS, A Schild)
Ligne: 19.5'''
Jewels: 2
Power Reserve: 14 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1940
Diameter: 44 mm
Height: 8.1 mm
Hands: 1.35 / 1.35 mm
The A. Schild 1266 is an open face calibre movement featuring a pin-lever escapement and a stop function with a pillar wheel. The pendant is mounted on the movement and the calibre signature is reasonably known. The movement incorporates a timer function with options for 60 seconds (with precision of 0.2 seconds) and 30 minutes. There is also an optional configuration available with a 30-second timer (with precision of 0.1 seconds) and a 15-minute timer. The movement is stem-wound and includes a sweep second hand. It was commonly used around the period of 1940.
The A. Schild 1266 features the following functions:
- Option: 30s (0.1s), 15min
- Stem wind
- Sweep second
- Timer function, 60s (0.2s), 30min, pillar wheel
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.95 x 0.200 x 360 x 15.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
