A. Schild 1256
(AS, A Schild)
Ligne: 11.5'''
Jewels: 17
Power Reserve: 43 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1970
Diameter: 26 mm
Height: 4.7 mm
Hands: 1.50 x 0.90 x 0.21 mm
The A. Schild 1256 watch movement features a unique design with the train and hand gear being driven separately by the barrel. Not much is known about the differences between the X171 and X172 variants of the movement. It offers a range of functions including manual wind, sweep seconds, date adjustment by changing 21:40-24h, shock protection, sweep seconds hand, and calendar. This movement was used primarily during the period of approximately 1970.
The A. Schild 1256 features the following functions:
- Calendar
- Date: set by changing 21:40-24h
- Manual Winding
- Shock Protection
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.20 x 0.130 x 300 x 9.5 mm | GR2988 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
