A. Schild 1245
(AS, A Schild)
Jewels: 17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: 1934-1951
Size: 18.7 x 24.2 mm
Height: 3.4 mm
Hands: 1.27 x 0.66 / 0.15 mm
The A. Schild 1245 watch movement, produced from 1934 to 1951, was designed for high-grade small-scale production and saw a production of less than 700,000 units. The movement featured a Breguet hairspring and functioned as a manual wind movement with a sub second display.
The A. Schild 1245 features the following functions:
- Manual Winding
- Sub Second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 3452 | Ordinary/None | Buy staff |
| 1212 | Ordinary/None | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
