A. Schild 1192
(AS, A Schild)
Ligne: 11.5'''
Jewels: 21/25
Lift Angle: 52°
Power Reserve: 47 hrs
Frequency: 21600 vph
Type: Automatic
Period used: ~1975
Diameter: 26 mm
Height: 5.3 mm
Hands: 1.50 x 0.90 x 0.25 mm
Base: ETA 2783
The A. Schild 1192 watch movement is an automatic movement with sweep seconds and quickset date function. It features Incabloc Shock Protection and a calendar display. This movement was utilized in watch models around 1975.
The A. Schild 1192 features the following functions:
- Automatic Winding
- Calendar
- Date: quickset
- Incabloc Shock Protection
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.120 x 368 x 10.5 mm | Auto | Buy mainspring | |
| 1.45 x 0.100 x 280 x 8.5 mm | GR3952X | Auto | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
