A. Schild 1071
(AS, A Schild)
Ligne: 14'''
Jewels: 17
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 31 mm
Height: 5.7 mm
Hands: 1.40 x 0.95 x 0.27 / 0.27 x 0.18 mm
The A. Schild 1071 watch movement is a manual-wind chronograph movement with a 60-second recording capability. It also incorporates a sub-second function. The movement is equipped with a pillar wheel mechanism and can measure elapsed times of 30 and 45 minutes. It was predominantly utilized in watches produced around the 1950s.
The A. Schild 1071 features the following functions:
- Manual-wind chronograph, 60s, 30/45 min, pillar wheel
- Sub Second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.130 x 430 x 12.5 mm | Manual | Buy mainspring | |
| 1.60 x 0.130 x 420 x 12.0 mm | GR4568 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| SET LEVER (W/SCREW) | 443/790 | Buy part |
