Return To ShopWatch Database
A. Schild 1018
(AS, A Schild)
Ligne: 12.5'''
Jewels: 17
Lift Angle: 48°
Power Reserve: 46 hrs
Frequency: 19800 vph
Type: Manual Wind
Period used: ~1965
Diameter: 28.4 mm
Height: 4.9 mm
Hands: 1.50 x 0.90 x 0.18 mm
The A. Schild 1018 watch movement is a manual wind mechanical movement that features a sweep second hand and a date function that can be set by changing the time between 21:15 and 24:00. This movement was commonly used during the period of approximately 1965.
The A. Schild 1018 features the following functions:
- Date: set by changing 21:15-24h
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.40 x 0.125 x 360 x 11.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|---|---|---|
| GIB | 480.19/INCA | Buy part | |
| JEWEL, INCA BALANCE 155X53X10 | 400/1413 | 411.10/INCA #61 | Buy part |
| JEWEL, INCA LOWER CAP 135X18 | 400/1412 | 422.11/INCA #50 | Buy part |
| JEWEL, INCA UPPER CAP 135X31 | 400/1411 | 421.11/INCA #49 | Buy part |
| LOWER SETTING D185 H10 | 400/1349 | 400.24.10 | Buy part |
| SCREW, INCA SHOCK 18X60 | 400/3 | 160.11/INCA #15 | Buy part |
| SPRING | 470.13/INCA | 400/1409 | Buy part |
| UPPER SETTING D325 H10 | 400/1351 | 400.11.325.10 | Buy part |
