A. Schild 1014
(AS, A Schild)
Ligne: 6.25'''
Jewels: 17
Power Reserve: 32 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1950
Diameter: 14 mm
Height: 3.4 mm
Hands: 1.00 x 0.50 mm
The A. Schild 1014 is a manual-wind watch movement that was commonly used in watches during the roughly 1950 period. The specific differences between the 106 and 106U are not known.
The A. Schild 1014 features the following functions:
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.30 x 0.060 x 180 x 5.5 mm | GR3171 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
