A Michel 549
Ligne: 11.5'''
Jewels: 17/21
Lift Angle: 52°
Power Reserve: 48 hrs
Frequency: 21600 vph
Type: Manual Wind
Period used: ~1970
Diameter: 26 mm
Height: 4.0 mm
Hands: 1.50 x 0.90 x 0.21 mm
The A Michel 549 watch movement, which was commonly used in manual wind watches around 1970, features a big balance and a low profile due to its indirectly driven minute hand. It also includes a sweep second function and a calendar with the date being set by changing the 20-24 hour position. The movement incorporates an Offset Center Wheel.
The A Michel 549 features the following functions:
- Calendar
- Date: set by changing 20-24h
- Manual Winding
- Offset Center Wheel
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|---|---|
| 5238 | Ordinary/None | Buy staff |
| 5238 | Incabloc | Buy staff |
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.45 x 0.100 x 360 x 9.5 mm | GR3956 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More | |||
| See More |
Documents
Parts Listing
