A Michel 500
Ligne: 12'''
Jewels: 15
Power Reserve: 45 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1951
Diameter: 26.6 mm
Height: 4.6 mm
Hands: 1.50 x 0.90 x 0.22 mm
Base: A Michel 394
The A Michel 500 watch movement is a manual wind movement with sweep second function, primarily used in watches around 1951. Not much information is available about this particular movement, including its ebauches origin and the exact differences between the 394, 396, and 397 variations.
The A Michel 500 features the following functions:
- Manual Winding
- Sweep second
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.70 x 0.120 x 340 x 10.5 mm | GR4936 | Manual | Buy mainspring |
| 1.70 x 0.120 x 320 x 10.5 mm | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
| Part Description | Reference # | Alternate | Buy |
|---|
