A Michel 397
Ligne: 10.5'''
Jewels: 7/15/17
Power Reserve: 40 hrs
Frequency: 18000 vph
Type: Manual Wind
Period used: ~1955
Diameter: 23.7 mm
Height: 4.9 mm
Hands: 1.40 x 0.80 x 0.18 mm
The A Michel 397 watch movement, originally known as the Eclipse 10.5''', was produced until approximately 1940. This manual wind movement features a sweep second hand and a calendar function. It was commonly used in watches around the year 1955.
The A Michel 397 features the following functions:
- Calendar
- Manual Winding
- Sweep second
Balance Staff Listing
| Ronda Reference # | Shock System | Buy |
|---|
Mainspring Listing
| Dimensions | GR Reference # | End Type | Buy |
|---|---|---|---|
| 1.60 x 0.100 x 290 x 9.0 mm | Manual | Buy mainspring | |
| 1.60 x 0.095 x 300 x 8.5 mm | GR4476 | Manual | Buy mainspring |
| 1.50 x 0.110 x 260 x 8.0 mm | GR4147 | Manual | Buy mainspring |
Incabloc Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) | |
|---|---|---|---|
| See More |
KIF Part Listing
| Block # (Top/Bottom) | Cap Jewel # (Top/Bottom) | Spring # (Top/Bottom) |
|---|
Documents
Parts Listing
